- Length: 3.6"
- Engine: 351D Secondary (Blue)
- Dragon” Light Engine by Charles Wiggins
- Multiple Light Modes (Programmable)
- Lithium Ion IMR 18350 Battery (Included)
- Black Mesh Rubber Push Button
- Source: New From Maker
The Pele is an incredible flashlight collaboration between Mike Bond of Ti2 Design and Charles Wiggins of CWF Lights. The attention to detail in this titanium light is insane. The Dragon V3 Engine gives this light programmable modes in a plethora of options. Instructions included.
Pele Dragon engine specs 3.7 volt driver fet primary output Linear secondary output Powered by a high drain 18350 40/400 lumens for secondary color From moonlight to 1500 lumens on Nichia and 2000 lumens on Samsung primary leds. Mode Groups: 1- low red,high red,ml,5,15,35,50,100 2- low red,high red,5,15,35,100 3- low red,ml,5,15,35,50,100 4- low red,5,15,35,100 5- low red,high red,15,100 6- low red,15,100 7- ML,5 ,15,35,50,100 8- 5,15,35,100 Reversing options(1/2second press) as follows: Turbo--->Strobe--->Batt Check (1-8 with 8 being full) ---> Bike Indicator Strobe Configuration Options: To enter configuration mode, quickly turn off the light 15+ times until it starts to flash. Once it starts to flash, you are in configuration mode. Once in configuration mode, the light will give a solid flash between 1 and 5 times. The number of solid flashes indicates the option number to be changed. To select/change the option turn the light off and back on during the strobing flashes that immediately follow the solid flashes. When you choose option 1 it will start to flash 1-8 times, turn off and back on after the number of the group you want comes up. When setting the temperature control the light will go from programming to turbo, turn the light off when it reaches the temperature you desire. 1. Mode Group Select. 2. Memory Toggle. 3. Mode Order Toggle. 4. Temperature Calibration Mode. 5. Reversing Toggle.
